| Wingspan |
1250 mm (49.2in) |
| Length |
930 mm (36.6in) |
| Flying Weight |
1280 g (52.9 oz) with 3S,11.1V,3300mAh,30C battery |
| Motor |
2212,KV800×2 brushless |
| Propeller |
7×6,3-Blade×2 |
| Cruising speed |
about 150 km/h |
| Flying time |
about 3～5 mins |
| Wing area |
20 dm2 |
| Wing load |
75 g/dm2 |
| Main material |
40 times the import of aeromodelling EPO |
| Painting surface |
Matte environmental water-borne paint(Part) + decal |
| Suitable experience level |
□Zero basis □Beginner ■Intermediate □Advanced |
| PNP Assembly difficulty |
□☆10mins ■★☆30mins □★★60mins |
| Suitable for ambient temperature |
0℃～40℃ |
| Radio System |
4 channel (required & not included) |
| ESC |
30A ×2(Standard XT60 Plug) |
| Servos |
9g×1 Plastic gear with Line length=380mm Rev: Nose gear steering
9g×2 Plastic gear with Line length=160mm: Left aileron, Right aileron
9g×1 Plastic gear with Line length=25mm: Left flap
9g×1 Plastic gear with Line length=25mm Rev: Right flap
9g×1 Plastic gear with Line length=100mm: Elevator
9g×1 Plastic gear with Line length=160mm: Rudder
|
| Recommended Power Battery |
3S,11.1V，3300 mAh，Li-Po with XT60 Plug(required & not included) |
| Ailerons |
Yes |
| Flaps |
Yes |
| Elevator(Horizontal tail) |
Yes |
| Rudder(Vertical tail) |
Yes |
| LED lights system |
Yes |
| Electromagnetic brake system |
No |
| Reinforced gyro |
Selective configuration (not included) |
| Packaging / Size |
Packing Box + Outer Box(Card mark)/1048×305×226(mm) |
| CG (Center of Gravity) |
65mm from the leading edge of the Main Wing |
| Landing Gears |
All Metal Electric Retractable（Steel Wire）×3 |
| Battery Charger |
LiPo battery charger (required & not included) |
