| Wingspan |
1890 mm (74.4 in) |
| Length |
1626 mm (64 in) |
| Flying Weight |
7kg (15.4 lb) |
| Flying time |
About 5 mins |
| Wing area |
52.3 dm2 |
| Wing load |
133.8 g/dm2 |
| Main material |
35 times EPO |
| Painting surface |
Matte environmental water-borne paint + decal |
| Suitable experience level |
□Zero basis □Beginner ■Intermediate □Advanced |
| PNP Assembly difficulty |
□☆10mins ■★☆30mins □★★60mins |
| Suitable for ambient temperature |
0℃～40℃ |
| Radio System |
7 channel (required & not included) |
| Control System |
MFC-2085-DR |
| Motor |
3560-1550KV(Outer rotor)×2 pcs |
| EDF |
S-EDF 90mm 12 Blade×2 pcs |
| ESC |
100A×2 pcs |
| Servos |
25g×2 Metal gear with 480mm lead (left & right ailerons forward)
25g×2 Metal gear with 330mm lead (left & right outer flap forward)
25g×1 Metal gear with 230mm lead (Vertical tail forward)
25g×4 Metal gear with 80mm lead (Elevator×2 & L/R inner flap forward)
7.4V 12g×1 Metal gear with 320mm lead with protection function (Nose wheel steering forward)
7.4V 12g×1 Metal gear with 320mm lead with protection function (Front wheel cover plate forward)
7.4V 12g×2 Metal gear with 80mm lead with protection function (Rear wheel cover plate forward)
|
| Recommended Power Battery |
6S,22.2V,5000～6000mAh,45C×2,LiPo with AS150 type plug(required & not included) |
| Recommended Receiver Battery |
2S,7.4V,1800～2000mAh×2,LiPo with XT60 type plug(required & not included) |
| Ailerons |
Yes |
| Flaps |
Yes |
| Elevator(Horizontal tail) |
Yes |
| Rudder(Vertical tail) |
Yes |
| LED lights system |
Yes |
| Electromagnetic brake system |
Yes |
| Reinforced gyro |
not included |
| Packaging / Size |
Packing Box + Outer Box(Card mark)/1400×525×335(mm) |
| CG (Center of Gravity) |
145～150mm from the leading edge of the Main Wing |
| Landing Gears |
All metal hydraulic simulation electric retractable landing gear×3 |
| Battery Charger |
LiPo battery charger (required & not included) |
