HSDJETS S-EDF 120mm HT-33 Thunderbirds Colors KIT*

PRE-ARRIVAL SALE! SAVE $50 SECURE YOUR JET! These aircraft have NOT ARRIVED yet, but the aircraft you purchase NOW will be shipped within 24 Business hours upon their arrival!

Be the first to review this product

Manufacturer: HSDJETS

Availability: 5 in stock

SKU: A52 01 03 00

Old price: $699.90

Price: $649.90

Qty:

Overview
Specifications
Videos
Parts
Reviews
Q&A
Manuals
Images

SPECIFICATIONS:

Wingspan	2018 mm (79.4 in)
Length	1800 mm (70.9 in)
Flying Weight	----
Cruising speed	----
Flying time	----
Wing area	56.5 dm²
Wing load	----
Main material	35 times EPO
Painting surface	Matte environmental water-borne paint + decal
Suitable experience level	□Zero basis □Beginner ■Intermediate □Advanced
PNP Assembly difficulty	□☆10mins □★☆30mins ■★★60mins
Suitable for ambient temperature	0℃～40℃
Radio System	7 channel (required & not included)
Control System	MFC-2085 (required & not included)
Motor	5268-640KV inner rotor (required & not included)
EDF	S-EDF120mm (required & not included)
ESC	Hobbywing 160A (required & not included)
Servos(required & not included)	7.4V 25g×2 Metal gear with 480mm lead (left & right ailerons forward) 7.4V 25g×2 Metal gear with 230mm lead (Flap×2 forward) 7.4V 25g×3 Metal gear with 80mm lead (elevator×2 & rudder×1 forward) 7.4V 12g×1 Metal gear with 380mm lead with protection function (Nose wheel steering forward) 7.4V 12g×1 Metal gear with 320mm lead with protection function (Front wheel cover plate forward) 7.4V 12g×2 Metal gear with 80mm lead with protection function (Rear wheel cover plate forward)
Recommended Power Battery	6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug(required & not included)
Recommended Receiver Battery	2S,7.4V,2200～32000mAh×2,LiPo with XT60 type plug(required & not included)
Ailerons	Yes
Flaps	Yes
Elevator(Horizontal tail)	Yes
Rudder(Vertical tail)	Yes
LED lights system	No
Electromagnetic brake system	No
Reinforced gyro	Selective configuration (not included)
Packaging / Size	Packing Box + Outer Box(Card mark)/52.56×21.3×16.9(inch)
CG (Center of Gravity)	180mm from the leading edge of the Main Wing
Landing Gears	Metal electric retractable hydraulic landing gear×3 (required & not included)
Battery Charger	LiPo battery charger (required & not included)

PACKAGE INCLUDES:

Fuselage×1 pcs
Left main wing×1 pcs
Right main wing×1 pcs
Left Horizontal tail ×1 pcs
Right Horizontal tail×1 pcs
Vertical tail×1 pcs
Nose×1 pcs
Cockpit×1 pcs
Left auxiliary tank×1 pcs
Right auxiliary tank×1 pcs
1# Main wing carbon tube L=820mm external diameter 16mm×1 pcs
2# Main wing carbon tube L=760mm external diameter 10mm×1 pcs
Horizontal Stabilizer carbon tube L=650mm external diameter 6mm×1 pcs
Accessories Bag 1 ×1 pcs
- Screw (HM3×10mm)×8 pcs (Horizontal tail)
- Screw (HA3×10mm)×8 pcs (Vertical tail / Tail nozzle)
- Screw (HA3×14mm)×8 pcs (Power)
- Screw (HM3×14mm)×8 pcs (Wing)
- Screw (HM4×25mm)×8 pcs (Auxiliary tank)
- Screw (PWM6×70mm)×6 pcs (Nose)
Accessories Bag 2 ×1 pcs
- 100mm signal line(JR male+JR male) ×8 pcs
HT-33 Manual×1 pcs
MFC-2085 Manual×1 pcs

REQUIRES:

7 channel radio system(radio & receiver) (required & not included)
6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug (required & not included)
2S,7.4V,2200～3200mAh×2,LiPo with XT60 type plug (required & not included)
LiPo battery charger (required & not included)

Product reviews for HSDJETS S-EDF 120mm HT-33 Thunderbirds Colors KIT*

Write your own review

Only registered users can write reviews
Product can be reviewed only after purchasing it

Review title: *

Review text: *

Rating:

Bad
Excellent

HSDJETS-S-EDF-120mm-HT-33-PNP-12S-Assembly-and-Debugging-Guide.pdf

HSDJETS-MFC-2085-ENGLISH-MENU-INTRODUCTION-QUICK-ENTRANCE.PDF

Q: What does KIT means?
A:It means aircraft comes without any electronic equipments, such as motor,ESC,servos,remote control,battery,etc. Clients have to buy these equipments themselves.

Q: What does KIT+L means?
A:It's a KIT version but comes with landing gear installed.

Q: What does PNP means?
A: It means the aircraft got equipments already installed and tested, but clients have to buy remote control,receiver,battery and the charger themselves. For example:servos,ESC,power system,landing gear,control system(UBEC included but no power supply), light cables(according to the model of aircrafts).It's a 90% installation.

Q: What does PNP+T means?
A: It's a PNP version with engine(general means turbine) installed and tested. It's a 95% installation.

Q: What does RTF means?
A: It means the aircraft comes with completely equipment installation(including battery supply,charger,remote control and receiver). It's a 100% installation.
