HSDJETS T-33 Foam Turbine Thunderbirds Colors KIT*

Be the first to review this product
Manufacturer: HSDJETS
Availability: In stock
SKU: A48 01 03 00
$799.90

SPECIFICATIONS:

Wingspan 2018 mm (79.4 in)
Length 1800 mm (70.9 in)
Weight 8.7kg (19.14 lb)
Turbine Engine SW80B 8KG brushless / SW60B 6KG brushless (required & not included)
Cruising speed 150～200 km/h (For reference only)
Flying time 3～5 mins (full throttle) (For reference only)
Wing area 56.5 dm2
Wing load 184.1 g/dm2 (For reference only)
Main material 20 times EPO
Painting surface matte paint
Suitable experience level □Zero basis □Beginner □Intermediate ■Advanced
KIT Assembly difficulty □☆10mins □★☆30mins ■★★60mins (For reference only)
Suitable for ambient temperature 0℃～40℃
Radio System 7 channel (required & not included)
Control System MFC-2085 (required & not included)
Servos(required & not included)

7.4V 25g×2 Metal gear with 480mm lead (left & right ailerons forward)
7.4V 25g×2 Metal gear with 230mm lead (Flap×2 forward)
7.4V 25g×3 Metal gear with 80mm lead (elevator×2 & rudder×1 forward)
7.4V 12g×1 Metal gear with 380mm lead with protection function (Nose wheel steering forward)
7.4V 12g×1 Metal gear with 320mm lead with protection function (Front wheel cover plate forward)
7.4V 12g×2 Metal gear with 80mm lead with protection function (Rear wheel cover plate forward)
Recommended Battery 2S,7.4V,5200mAh×2,LiPo with XT60 type plug(required & not included)
Ailerons Yes
Flaps Yes
Elevator(Horizontal tail) Yes
Rudder(Vertical tail) Yes
The smoke system No
LED lights system Selective configuration (not included)
Electromagnetic brake system Selective configuration (not included)
Reinforced gyro Selective configuration (not included)
Packaging / Size Packing Box + Outer Box(Card mark)/52.56×21.3×16.9(inch)
CG (Center of Gravity) 180mm from the leading edge of the Main Wing
Landing Gears Metal electric retractable hydraulic landing gear×3 (required & not included)
Battery Charger LiPo battery charger (required & not included)

Does not include decals in "Kit" version.
