HSDJETS Turbine Super Viper New Red Colors KIT(Stickers not affixed)

Manufacturer: HSDJETS-202501
Availability: 1 in stock
SKU: A15 06 03 00
$699.90

SPECIFICATIONS:

Wingspan 1500mm (59.1in)
Length 1663mm (65.5in)
Flying Weight ---
Turbine Engine SW60 6KG brushed / SW60B 6KG brushless (required & not included)
Cruising speed --- km/h
Flying time ---
Wing area 34.28 dm2
Wing load --- g/dm2
Main material 20 times EPO
Painting surface matte paint
Suitable experience level Intermediate
PNP Assembly difficulty □☆10mins ■★☆30mins □★★60mins
Suitable for ambient temperature 0℃~40℃
Radio System 8 channel (required & not included)
Control System MFC-2085 (required & not included)
Servos (required & not included)

25g×2 Metal gear with 480mm lead (left & right ailerons forward)
25g×3 Metal gear with 190mm lead (Flap×2 & rudder×1 forward)
25g×2 Metal gear with 80mm lead (elevator forward)
12g×1 Metal gear with 300mm lead (Nose wheel steering forward)
12g×1 Metal gear (360°lock Hatch cover forward)

Recommended Battery 2S,7.4V,1800~2000mAh×2,LiPo with T type plug(required & not included)
Ailerons Yes
Flaps Yes
Elevator(Horizontal tail) Yes
Rudder(Vertical tail) Yes
The smoke system not included
LED lights system not included
Electromagnetic brake system not included
Reinforced gyro not included
Packaging / Size Packing Box + Outer Box(Card mark)/132.5×46×39.5(cm)
CG (Center of Gravity) 170mm from the leading edge of the Main Wing
Landing Gears Metal electric retractable hydraulic landing gear×3 (required & not included)
Battery Charger LiPo battery charger (required & not included)



PACKAGE INCLUDES:

  • Fuselage×1
  • Left Wing×1
  • Right Wing×1
  • Left Horizontal Stabilizer×1
  • Right Horizontal Stabilizer×1
  • Vertical Stabilizer×1
  • Nose×1
  • Cockpit canopy×1
  • Main wing carbon tube L=598mm external diameter 16mm×1
  • Horizontal Stabilizer carbon tube L=500mm external diameter 6mm×1
  • Sticker×1
  • Capping board×1
  • Accessories Bag 1 ×1
    • Nylon rocker arm of the servo ×2
    • Double sided sponge paper×1
    • Screw (HM4×35mm)×4 (Nose)
    • Screw (HM3×14mm)×2 (Wing)
    • Screw (HM3×10mm)×2 (Wing)
    • Screw (PA3×14mm)×4 (Engine)
    • Screw (PA3×10mm)×4 (Tail nozzle)
    • Screw (PA3×8mm)×8 (Horizontal Stabilizer/Vertical Stabilizer)
  • Accessories Bag 2 ×1
    • L type 3mm inner six corner board hand×1
    • Screw (HM4×35mm)×4 (Nose)
    • Screw (HM3×14mm)×2 (Wing)
    • Screw (HM3×10mm)×2 (Wing)
    • Screw (PA3×14mm)×4 (Engine)
    • Screw (PA3×8mm)×8 (Horizontal Stabilizer/Vertical Stabilizer)
  • Manual×1(Downloadable on website)

REQUIRES:
  • SW60 6KG brushed / SW60B 6KG brushless (required & not included)
  • 8 channel radio system(radio & receiver) (required & not included)
  • 2S,7.4V,1800~2000mAh×2,LiPo with T type plug (required & not included)
  • LiPo battery charger (required & not included)
  • MFC-2085 (required & not included)
  • Servos (required & not included)
  • Smoke system
  • LED lights system (required & not included)
  • Brake system (required & not included)






Write your own review
  • Only registered users can write reviews
  • Product can be reviewed only after purchasing it
*
*
  • Bad
  • Excellent

Q: What does KIT means?
A:It means aircraft comes without any electronic equipments, such as motor,ESC,servos,remote control,battery,etc. Clients have to buy these equipments themselves.

Q: What does KIT+L means?
A:It's a KIT version but comes with landing gear installed.

Q: What does PNP means?
A: It means the aircraft got equipments already installed and tested, but clients have to buy remote control,receiver,battery and the charger themselves. For example:servos,ESC,power system,landing gear,control system(UBEC included but no power supply), light cables(according to the model of aircrafts).It's a 90% installation.Note: turbojet series products do not include turbojet engine.

Q: What does PNP+T means?
A: It's a PNP version with engine(general means turbine) installed and tested. It's a 95% installation.

Q: What does RTF means?
A: It means the aircraft comes with completely equipment installation(including battery supply,charger,remote control and receiver). It's a 100% installation.
